Compute Module Specifications
007-4566-001
Table A-2 lists the bandwidth characteristics of the compute module.
Table A-2 Bandwidth Characteristics of the Compute Module
Characteristic Peak Bandwidth
NUMAlink 3.2 GB/s full duplex
channel
1.6 GB/s each direction
Xtown2 channel 2.4 GB/s full duplex
1.2 GB/s each direction
Main memory 3200 MB/s
SYSAD 1600 MB/s
Table A-3 summarizes the general features of the compute module.
Note: The following table assumes that the expansion compute module does not include
an optional IO9 PCI card, which would add one input and one output real-time interrupt
port, an Ethernet port, and an internal and external SCSI drive, and support for one serial
port. The IO9 card is also needed to support the DVD-ROM, the SCSI disc drives, and the
serial daughtercard with the PS/2 connectors and three serial ports (this serial
daughtercard is not an option for the expansion compute module).
Table A-3 General Features of the Compute Module
Feature
NUMAlink port
XIO port
Console port
Serial ports
L1 port
PS/2 ports
Sustainable Bandwidth
~1420 MB/s each direction
~1066 MB/s half duplex
~1744 MB/s full duplex, ~872 MB/s each direction
2140 MB/s
~1400 MB/s
Base Compute Module
1 (1.6 GB/s each direction)
1 (800 MB/s each direction)
1
4
1
One keyboard and one mouse port

Compute Module Specifications

Expansion Compute Module
1 (1.6 GB/s each direction)
1 (800 MB/s each direction)
1
a
1
1
