2: System Overview
82
• One or more power components (for example, power distribution unit (PDU),
power strip, and power bay module).
Note: The power bay is required when the system contains a PCI expansion module.
• One or more TP900 storage modules (optional). (The maximum number of TP900s
is dependent on the number of SCSI connections in the system; each TP900 requires
one SCSI connection.)
• 2Gb SGI TP9100 storage system, SGI TP9400 storage system, or SGI TP9500 storage
system (optional).
Compute modules
NUMAlink module
Compute modules
Figure 2-8 Component Example of NUMAlink Configuration
007-4566-001
