007-4566-001
7. If you are removing a card from one of the two lowermost card slots, remove the
chassis rail, by unscrewing the five Phillips screws as shown in Figure 6-11. (If you
are not removing a PCI/PCI-X card from one of the two lowermost card slots,
proceed to step 9.)
Caution: Only a trained SGI service support engineer can install and remove an IO9
!
card. Otherwise, your system could be damaged. Therefore, if an IO9 card is installed
in your system (it is always installed in the lowermost slot), you can remove a card
only from the upper three slots.
Removing the Chassis Rail
Figure 6-11
PCI and PCI-X Cards
169
