DVD-ROM

Disk Drives

007-4566-001
The compute module can contain an optional slim-line DVD-ROM that has CD-ROM
capabilities.
Note: The DVD-ROM requires an IO9 PCI card.
The DVD-ROM is located at the front left side of the module (above the disk drives).
The base compute module supports one or two sled-mounted Ultra3 SCSI disk drives
that have a peak data transfer speed of up to 160 MB/s between the disks and system
memory. The two disks connect to a SCSI backplane. The SCSI backplane connects to the
internal SCSI 160 logic on the IO9 PCI card.
Note: An expansion compute module can also be ordered with SCSI disk drives. This
configuration requires an IO9 PCI card.
Two disk drive sizes are available, as follows:
• 18-GB 15,000-RPM disk drive
• 73-GB 10,000-RPM disk drive
The disk drives are located at the front left side of the module (below the DVD-ROM).
The master drive is the bottom drive.
