The USB hub (see Figure A-6) has four USB type A connectors (two connectors on each
side of the hub). Figure A-11 on page 233 shows how the pin numbers are distributed on
the USB type A connector, and Table A-24 on page 233 lists the pin assignments.
USB Hub Type A Connectors
Figure A-6
USB type A
connectors
