6: Installing and Removing Customer-replaceable Units
!
160
7. If you are installing a card in one of the two bottom-most card slots, you must also
remove the chassis rail by unscrewing the five Phillips screws, as shown in
Figure 6-3. (If you are not installing a card into one of the bottom-most card slots,
proceed to step 9.)
Caution: Your system may or may not have a factory-installed IO9 card, which
always comes installed in the lowermost slot. To prevent damage to your system,
only a trained SGI service support engineer can install or remove an IO9 card.
Removing the Chassis Rail
Figure 6-3
007-4566-001
