Removing a DIMM

007-4566-001
To remove a DIMM, follow these steps:
1. Power off the server system. For powering off instructions, see "Powering the
Server System On and Off" on page 53.
2. Disconnect all of the cables at the rear of the module.
Warning:
Components may be hot. To avoid injury, allow the components to cool
for approximately five minutes before you proceed with these instructions.
3. Remove the two screws that secure the module to the front rails of the rack.
4. Pull the module from the rack until it is stopped by the safety latches.
5. To access the DIMMs, remove the ten Phillips screws shown in Figure 6-28 and open
the hinged cover.
Figure 6-28 Opening Module to Remove DIMM
Memory
193
