Table A-18 lists the non-proprietary connectors that are located on the rear panel of the
compute module (see Figure A-1). The third column of the table indicates where you can
find the pin assignments for these connectors.
Table A-18 Compute Module Connectors
Port
Serial ports 1 through 4 a
Console port
Keyboard and mouse ports
Ethernet port c
External SCSI port d
RT interrupt input and
output ports e
L1 port
a. Serial ports 2, 3, and 4 reside on a daughtercard. This daughtercard is only available with the base
compute module.
b. The keyboard and mouse PS/2 ports are available on the daughtercard. This daughtercard is only
available with the base compute module.
c. These connectors are available only when the compute module has an IO9 PCI card.
d. These connectors are available only when the compute module has an IO9 PCI card.
e. These connectors are available only when the compute module has an IO9 PCI card.
Connector
DB-9
DB-9
b PS/2
RJ-45
SCSI 68-pin VHDCI
Stereo jack
USB type B
Pin Assignments
See Figure A-7 on page 228
See Figure A-7 on page 228
See Figure A-13 on page 235 and
Table A-26 on page 235
See Figure A-8 on page 229 and
Table A-21 on page 229
See Figure A-9 on page 230 and
Table A-22 on page 230
See Figure A-10 on page 232 and
Table A-23 on page 232
See Figure A-12 on page 234 and
Table A-25 on page 234
