Rack Specifications - Silicon Graphics Origin 350 User Manual

A: Technical Specifications
Rack Specifications
218
The Origin 350 server system can be housed in short (17U) or tall (39U) racks.
Note: One U is 1.75 in. (4.45 cm).
Table A-12 lists the specifications of the short rack.
Table A-12 Short Rack Specifications (with Skins)
Characteristic
Height
Width
Depth
Weight (maximum)
Shipping weight (maximum)
Table A-13 lists the specifications of the tall rack.
Table A-13 Tall Rack Specifications
Characteristic
Height
Width
Depth
Weight (maximum)
Shipping weight (maximum)
Specification
36.06 in. (916 mm)
25.38 in. (645 mm)
40.63 in. (1032 mm)
488 lb (221 kg)
563 lb (255 kg)
Specification
75.82 in. (1925.83 mm)
23.62 in. (599.95 mm)
41.25 in. (1048 mm)
1,100 lb (499 kg)
1,281 lb (581 kg)
007-4566-001
