▼ Install the Battery

1. Unpack the replacement battery.
2. Press the new battery into the battery retainer with the positive side (+) facing
up (see
3. If the service processor is configured to synchronize with a network time server
using the Network Time Protocol (NTP), the Oracle ILOM clock will be reset as
soon as the server is powered on and connected to the network; otherwise,
proceed to the next step.
4. If the service processor is not configured to use NTP, you must do the following:
a. Reset the Oracle ILOM clock using the Oracle ILOM CLI or the web
b. Use the BIOS Setup Utility to reprogram the host clock.
5. Return the server to operation.
a. Install the server top cover.
b. Close the fan door.
c. Return the server to the normal rack position.
d. Reconnect the power cords to the server power supplies and reconnect the
e. Power on the server.
Note – On first boot, use the BIOS Setup utility to reset the server host time.
98 Sun Server X4-2 Service Manual • May 2014
FIGURE: Removing the Battery on page
interface.
For instructions, see the Oracle Integrated Lights Out Manager (ILOM) 3.1
Documentation Library at: http://www.oracle.com/goto/ILOM/docs.
For the BIOS Main menu screen that supports this procedure, see the Oracle X4
Series Servers Administration Guide at
http://www.oracle.com/goto/x86AdminDiag/docs.
See "Install the Server Top Cover" on page
See "Return the Server to the Normal Rack Position" on page
data cables.
See "Reconnect Data Cables and Power Cords" on page
See "Power On the Server" on page
Verify that the Power/OK status indicator is steady on.
97[1]).
145.
149.
150.
148.
