Identifying the Server Ports

This section describes the pinouts of the server connectors.
Description
Learn about the Gigabit Ethernet ports.
Learn about the network management
port.
Learn about the serial management port.
Learn about the video connector.
Learn about USB ports.

Gigabit Ethernet Ports

The server has four auto-negotiating 100/1000/10,000BASE-T gigabit Ethernet (GbE)
system domain ports. All four Ethernet ports use a standard RJ-45 connector.
The transfer rates are shown in the following table:
Ethernet Port Transfer Rates
TABLE:
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
The following figure and table describe the 10-GbE port pin signals.
Links
"Gigabit Ethernet Ports" on page 153
"Network Management Port" on page 154
"Serial Management Port" on page 155
"Video Connector" on page 157
"USB Ports" on page 158
IEEE Terminology
100BASE-TX
1000BASE-T
10GBASE-T
Transfer Rate
100 Mbps
1,000 Mbps
10,000 Mbps
