Servicing Pcie Cards (Cru) - Sun Oracle Sun Server X4-2 Service Manual

Related Information
"Remove a PCIe Riser From PCIe Slots 3 and 4" on page 80
■

Servicing PCIe Cards (CRU)

These sections describe how to remove and install PCIe cards. Refer to your PCIe
card documentation for complete software and cabling information about your card.
In addition to the service procedures included here, you can see animations that
show how to remove and install the PCIe cards.
To play the Sun Server X4-2 Service Animations go to:
http://docs.oracle.com/cd/E36975_01/html/E49470/index.html
Caution – These procedures require that you handle components that are sensitive
to electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in
Measures" on page
Caution – Ensure that all power is removed from the server before removing or
installing PCIe cards. You must disconnect all power cables from the system before
performing these procedures.
Note – For a complete list of supported PCIe cards, see the Sun Server X4-2 Product
Notes at http://www.oracle.com/goto/X4-2/docs.
The following sections provide information to assist you when servicing PCIe cards:
"PCIe Slot Characteristics" on page 85
■
"Remove a PCIe Card From PCIe Slot 1 or 2" on page 86
■
"Install a PCIe Card in PCIe Slot 1 or 2" on page 87
■
"Remove a PCIe Card From PCIe Slot 3" on page 87
■
"Install a PCIe Card in PCIe Slot 3" on page 88
■
"Remove the Internal HBA Card From PCIe Slot 4" on page 89
■
84 Sun Server X4-2 Service Manual • May 2014
42.
"Take Antistatic
