Note – A maximum of eight DIMMs for a maximum of 256 GB are supported in
single-processor systems.
Four PCIe Gen3 slots in dual-processor systems: three external slots and one
■
internal. PCIe slot 1, which is an external slot, is nonfunctional in single-processor
systems.
Storage drive configurations can include both hard disk drives (HDDs) or solid
■
state drives (SSDs). Supported storage drive configurations include:
■
■
Two hot-pluggable, redundant power supplies.
■
An on-board Oracle Integrated Lights Out Manager (Oracle ILOM) service
■
processor (SP) based on the AST2300 chip.
The Oracle System Assistant server setup tool, which is embedded on a
■
preinstalled USB flash drive.

About Controls and Connectors

The following sections describe the controls, indicators, connectors, and drives
located on the front and rear panels.
"Front Panel Controls and Indicators on a System With Eight 2.5-inch Drives" on
■
page 3
"Front Panel Controls and Indicators on a System With Four 2.5-inch Drives and
■
DVD Drive" on page 4
"Server Back Panel View" on page 5
■
Related Information
"About Server and Component Status Indicators" on page 6
■
"About System Components" on page 15
■
"Illustrated Parts Breakdown" on page 15
■
2 Sun Server X4-2 Service Manual • May 2014
Eight 2.5-inch hot-pluggable SAS HDDs/SATA SSDs
Four 2.5-inch hot-pluggable SAS HDDs/SATA SSDs with DVD
