BIOS Advanced Menu Options (Continued)
TABLE:
Setup Options
Commit
IPv4 Configuration (R/O)
Channel Number (R/O)
IPv4 Assignment (R/O)
Current IPv4 Address in
BMC (R/O)
Current IPv4 MAC
Address in BMC (R/O)
Current IPv4 Subnet Mask
in BMC (R/O)
Refresh
IPv4 Address
IPv4 Subnet Mask
IPv4 Default Gateway
Commit
210 Sun Server X4-2 Service Manual • May 2014
Options
Static/Dynamic
Defaults
1
Static
Description
Commit the current BMC
network information.
Current configuration of the IPv4
settings is displayed.
Current channel number is
displayed.
View whether the service
processor is assigned a static
IPv4 address or assigned a
dynamic IPv4 address using
Dynamic Host Control Protocol
(DHCP).
Current IPv4 address of the
service processor is displayed.
Example: 172.31.255.255
Current IPv4 MAC address for
the service processor is
displayed.
Example: 00:12:46:BE:0A:02
Current IPv4 subnet mask
address for the service processor
is displayed.
Example: 255.255.255.0
Select Refresh to update to the
current settings.
If IPv4 Assignment is set to
Static, set the IPv4 address for
the service processor.
Example: 172.31.255.255
If the IPv4 Assignment is set to
Static, set the IPv4 subnet mask.
Example: 255.255.255.0
If the IPv4 Assignment is set to
Static, set the IPv4 default
gateway
Example: 172.31.255.255
Commit the IPv4 configuration
settings.
