b. Continue pushing the server into the rack until the slide-rail locks (on the
front of the server) engage the slide-rail assemblies.
You will hear an audible click when the server is in the normal rack position.
2. If the CMA is not installed, that is, you removed it because you removed the
server completely out of the rack, install the CMA.
For installation instructions for the CMA, see one of the following procedures,
depending on which version of the CMA is installed on your server:
Sun Server X4-2 Installation Guide, "Install the Second-Generation Cable
■
Management Arm" on page 52
Sun Server X4-2 Installation Guide, "Install the First-Generation Cable
■
Management Arm" on page 69
3. If the cables are disconnected from the rear of the server, that is, you
disconnected the cables because you removed the server completely out of the
rack, reconnect the cables.
For instructions on reconnecting cables to the rear of the server, see
■
Data Cables and Power Cords" on page
For detailed information on connecting cables to the rear of the server, see
■
Server X4-2 Installation Guide, "Rear Cable Connections and Ports" on page
Related Information
"Reconnect Data Cables and Power Cords" on page 149
■
▼ Reconnect Data Cables and Power
Cords
1. Reconnect the data cables to the rear of the server, as required.
If the cable management arm (CMA) is in the way, extend the server
approximately 13 cm (5 inches) out of the front of the rack.
2. Reconnect the power cables to the power supplies and secure them with the
Velcro straps as shown in the following figure.
149.
