About Server And Component Status Indicators - Sun Oracle Sun Server X4-2 Service Manual

(Continued)
Figure Legend
4 Power Supply (PS) 1 status indicators:
Service Required LED: amber,
AC OK LED: green
5 System status indicators:
Locator LED: white,
Service Required LED: amber,
Power/OK LED: green
6 PCIe card slot 1 (Nonfunctional in
single-processor systems.)
7 PCIe card slot 2
8 PCIe card slots 3 and 4 (Slot 4 is the primary
host bus adapter (HBA) card slot. This slot is
internal and is not visible from the rear of the
server. The server supports a maximum of
one HBA card for controlling and managing
the server storage drives.)
Note – All of the PCIe slots comply with the PCI Express 3.0 specification and can
accommodate 25 watt PCIe3 cards.
Related Information
"Front Panel Controls and Indicators on a System With Eight 2.5-inch Drives" on
■
page 3
"Front Panel Controls and Indicators on a System With Four 2.5-inch Drives and
■
DVD Drive" on page 4
"About System Components" on page 15
■
About Server and Component Status
Indicators
These sections describe the status indicators (LEDs) located on the front and rear of
the server, including those found on components and ports.
"Server General Status Indicators" on page 7
■
"Server Fan Status Indicators" on page 9
■
"Storage Drive Status Indicators" on page 10
■
6 Sun Server X4-2 Service Manual • May 2014
12 Network (NET) 100/1000/10000 port: NET 2
(Nonfunctional in single-processor systems.)
13 Network (NET) 100/1000/10000 port: NET 1
14 Network (NET) 100/1000/10000 port: NET 0
15 USB 2.0 connectors (2)
16 DB-15 video connector
