4. Ensure that the rear bracket on the internal HBA card in PCIe slot 4 is connected
to the slot in the server chassis side wall.
If the bracket is not connected, remove the riser and reposition it so that the rear
bracket connects to the side wall, and then gently press the riser into the
motherboard connector.
5. Slide the plastic PCIe card retainer, which is mounted on the side of the chassis,
toward the back of the server to secure the card(s) installed in the riser [3].
6. Press the green-tabbed release lever on the PCIe riser to the closed (down)
position [4].
7. To secure the rear bracket on the PCIe card to the server, close the green-tabbed
latch on the rear of the server chassis [5].
Note – If the riser does not have a PCIe card installed in slot 3, install a PCIe slot
filler panel and close the green-tabbed latch to secure the PCIe slot filler panel.
8. If there is a PCIe card installed in slot 3 of the riser, reconnect any external or
internal cables to the card.
9. Return the server to operation.
a. Install the server top cover.
See "Install the Server Top Cover" on page
b. Close the fan door.
c. Return the server to the normal rack position.
See "Return the Server to the Normal Rack Position" on page
d. Reconnect the power cord to the server power supply and the data cables.
See "Reconnect Data Cables and Power Cords" on page
e. Power on the server.
See "Power On the Server" on page
Verify that the Power/OK status indicator is steady on.
10. Use Oracle ILOM to clear the server PCIe riser fault.
If the PCIe riser fault message in Oracle ILOM is not cleared under Open
Problems, you must manually clear the fault in Oracle ILOM. For instructions for
manually clearing a PCIe riser fault, see the procedure "Clear Faults for
Undetected Replaced or Repaired Hardware Components" in the Oracle Integrated
Lights Out Manager (ILOM) 3.1 User's Guide in the Oracle Integrated Lights Out
Manager (ILOM) 3.1 Documentation Library at
http://www.oracle.com/goto/ILOM/docs.
