Remove The Internal Hba Card From Pcie Slot 4 - Sun Oracle Sun Server X4-2 Service Manual

4. Install the PCIe riser.
For instructions, see

▼ Remove the Internal HBA Card From PCIe Slot 4

1. Remove the PCIe riser from slots 3 and 4.
For instructions, see
2. Remove the internal host bus adapter card from the riser.
a. Hold the riser in one hand and use your other hand to carefully remove the
card from slot 4 of the riser.
b. Disconnect the rear bracket attached to the PCIe card from the rear of the
PCIe riser.
"Install a PCIe Riser Into PCIe Slots 3 and 4" on page
"Remove a PCIe Riser From PCIe Slots 3 and 4" on page
Servicing CRUs That Require Server Power-Off
82.
80.
89
