Storage Drives Hot-Plug Conditions; Hdd Or Ssd Failure And Raid - Sun Oracle Sun Server X4-2 Service Manual

"Storage Drives Hot-Plug Conditions" on page 46
■
"HDD or SSD Failure and RAID" on page 46
■
"Storage Drive Status Indicators" on page 47
■
"Remove a Storage Drive" on page 47
■
"Install a Storage Drive" on page 49
■
Related Information
"Removing and Installing Server Filler Panels" on page 143
■

Storage Drives Hot-Plug Conditions

The solid-state drives (SSDs) or hard-disk drives (HDDs) in the server are
hot-pluggable, but this capability depends on how the drives are configured. To
hot-plug a drive you must be able to take the drive offline before you can remove it.
When you take the drive offline, you prevent any application from accessing the
drive and remove the logical software links to the drive.
The following situations inhibit the ability to perform hot-plugging of a drive:
The drive provides the operating system, and the operating system is not mirrored
■
on another drive.
The drive cannot be logically isolated from the online operations of the server.
■
If either of the above drive restrictions is true, then you must shut down the system
before you replace the drive. See
Note – Replacing a drive does not require removing the server from a rack.
Related Information
"Remove a Storage Drive" on page 47
■
"Install a Storage Drive" on page 49
■

HDD or SSD Failure and RAID

A single storage drive failure does not cause a data failure if the storage drives are
configured as a mirrored RAID 1 volume (optional). The storage drive can be
removed, and when a new storage drive is inserted, the contents are automatically
46 Sun Server X4-2 Service Manual • May 2014
"Powering Down the Server" on page 33.
