BIOS Advanced Menu Options (Continued)
TABLE:
Setup Options
Internal Port 1
SERIAL PORT CONSOLE
REDIRECTION
External Serial Port
EMS Console Redirection
Console Redirection
Terminal Type
Bits per Second
Data Bits
Options
Disabled/Enabled
System/BMC
Disabled/Enabled
Disabled/Enabled
VT100/
VT100+/
VT-UTF8/
ANSI
9600/
10200/
57600/
115200
07/
08/
11
Defaults
Enabled
System
Disabled
Enabled
VT100+
9600
8
BIOS Setup Utility Menu Options
Description
Enable or disable USB Port 5.
Provides the capability to
redirect console output/input to
the serial port. Graphic output is
not redirected. BIOS serial
console redirection lets you
monitor BIOS POST messages
and navigate the BIOS Setup
Utility menus and Option ROMs
from a terminal connected to the
server using a serial connection.
Control whether the external
serial port connects to the
Baseboard Management
Controller (BMC) or directly to
the system. Set to BMC for serial
link management.
Enable or disable console
redirection for Windows
Emergency Management Service
(EMS) administration.
Enable or disable console
redirection.
Select the emulation for the
terminal:
• VT100: ASCII character set.
• VT100+: Extends VT100 to
support color, function keys,
etc.
• VT-UTF8: Uses UTF8 encoding
to map Unicode characters
onto one or more bytes.
• ANSI: Extended ASCII
character set.
Select the serial port
transmission speed. The speed
must be matched on the
connecting serial device. Long or
noisy lines require lower speeds.
Select the data bits.
