Servicing the Front Indicator Module
(FRU)
Caution – Ensure that all power is removed from the server before removing or
installing a front indicator module. You must disconnect the power cables from the
server before performing these procedures.
Follow these procedures to remove and install the front indicator module (FIM).
"Remove the Front Indicator Module" on page 125
■
"Install the Front Indicator Module" on page 127
■
Related Information
"Disconnect Cables From the Server" on page 39
■
"Remove the Server From the Rack" on page 41
■
"Take Antistatic Measures" on page 42
■
"Open the Server Fan Door" on page 43
■

▼ Remove the Front Indicator Module

1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server to the maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
2. To remove the top cover from the storage drive cage, do the following:
a. Remove the six Phillips screws from the top of the storage drive cage [1].
There are three Phillips screws on each side of the storage drive cage.
33.
42.
Servicing FRUs
39.
125
