Processor Components

The following table lists the processor (CPU) components.
Component Name (Oracle
ILOM CLI Targets)
/SYS/MB/P[0-1]
/SYS/MB/P[0-1]/PRSNT
/SYS/MB/P[0-1]/SERVI
CE
/SYS/MB/P[0-1]/V_DI
MM
Related Information
"System Chassis Components" on page 229
■
"Cooling Unit Components" on page 231
■
"Disk Backplane Components" on page 232
■
"Memory Device Components" on page 232
■
"Power Unit Components" on page 233
■
"System Board Components" on page 235
■
"System Firmware Components" on page 237
■
"Hard Disk Drive Components" on page 238
■

System Board Components

The following table lists the system board components.
Component Name (Oracle ILOM
CLI Targets)
/SYS/MB
/SYS/MB/NET[0-3]
IPMI Type Description
FRU Host CPU FRU
Discrete Host CPU is present.
sensor
Indicator Host CPU Service
LED
Static CPU's DIMM bank
sensor operating voltage
IPMI Type Description
FRU General host system
board FRU
FRU Host Ethernet FRU
Monitoring Components and Identifying SNMP Messages
Values
(if applicable)
01h-ENTITY_PRESENT,
02h-ENTITY_ABSENT
Color: Amber
Location: Mainboard
Off: Normal
On: Processor was
diagnosed as faulty.
LVDIMM = 1.3V
non-LVDIMM = 1.5V
Values
(if applicable)
