▼ Install the Front Indicator Module

1. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page 42
2. Unpack the replacement FIM and place it on an antistatic mat.
3. Connect the FIM cable to the replacement FIM assembly [3].
See FIGURE: Removing the Front Indictor Module on page
4. Carefully lower the FIM assembly into the chassis, position it over the Phillips
screw in the server chassis, and slide it forward so all the LEDs, USB
connectors, and Power On button fit into place on the server front panel [2].
5. Tighten the Phillips screw to secure the FIM assembly to the server chassis [2].
6. Place the storage drive cage cover over the server storage drive cage and install
the six Phillips screws to secure the cover to the server.
There are three Phillips screws on each side of the storage drive cage.
7. Ensure that server fan door is closed.
8. Return the server to operation.
a. Return the server to the normal rack position.
See "Return the Server to the Normal Rack Position" on page
b. Reconnect the data cables to the server and reconnect the power cords to the
server power supplies.
See "Reconnect Data Cables and Power Cords" on page
c. Power on the server.
See "Power On the Server" on page
Verify that the Power/OK status indicator is steady on.
Related Information
"Remove the Front Indicator Module" on page 125
■

Servicing the Motherboard (FRU)

Follow these procedures to remove and install the motherboard.
126.
149.
150.
148.
Servicing FRUs 127
