Sun Oracle Sun Server X4-2 Service Manual page 180

2. Use the left and right arrow keys to select the different primary menu options.
As you select each menu option, the top-level screen for that menu option
appears.
3. To navigate the options presented on a top-level screen, use the up and down
arrow keys.
Only options that can be modified are highlighted when you press the up and
down arrow keys.
■
■
4. Modify an option by pressing the + or - keys (plus or minus keys) or by
pressing Enter and selecting the desired option from the pop-up menus.
5. Press the Esc key to return from a sub-menu screen to the previous menu screen.
Pressing Esc from a top-level menu is equivalent to selecting the Discard Changes
and Exit option from the Save & Exit Menu.
6. Modify parameters as needed.
7. Press F10 to save your changes and exit the BIOS Setup Utility.
Alternatively, you can select the Save & Exit Menu, and then select the Save
Changes and Reset to save your changes and exit the BIOS Setup Utility.
Note – After modifying any BIOS settings and selecting Save Changes and Reset
from the Save & Exit Menu, the subsequent reboot might take longer than a typical
reboot where no settings were modified. The additional delay is required to ensure
that changes to the BIOS settings are synchronized with Oracle ILOM.
Related Information
"BIOS Setup Utility Menus" on page 162
■
"BIOS Key Mappings" on page 163
■
"BIOS Setup Utility Menu Options" on page 197
■
166 Sun Server X4-2 Service Manual • May 2014
If an option can be modified, as you select the option, user instructions for
modifying the option appear in the right column of the screen.
If an option is a link to a sub-screen, a description of the sub-menu content
appears in the right column.
