c. Push the DDR3 DIMM into the connector until the ejector tabs lock the
4. Repeat
5. Return the server to operation.
a. Install the server top cover.
b. Close the fan door.
c. Return the server to the normal rack position.
d. Reconnect the power cords to the server power supplies and reconnect the
e. Power on the server.
6. (Optional) Use Oracle ILOM to clear server DDR3 DIMM faults.
DDR3 DIMM faults are automatically cleared after a new memory DIMM has been
installed. If you need to manually clear DDR3 DIMM faults, refer to the Oracle
Integrated Lights Out Manager (ILOM) 3.1 Documentation Library at
http://www.oracle.com/goto/ILOM/docs.

Servicing PCIe Risers (CRU)

This section describes how to remove and install the PCIe risers.
In addition to the service procedures included here, you can see animations that
show how to remove and install the PCIe risers.
74 Sun Server X4-2 Service Manual • May 2014
DIMM in place.
If the DIMM does not easily seat into the connector socket, verify that the notch
in the DIMM is aligned with the connector key in the connector socket. If the
notch is not aligned, damage to the DIMM might occur.
Step 3 until all replacement DDR3 DIMMs are installed.
See "Install the Server Top Cover" on page
See "Return the Server to the Normal Rack Position" on page
data cables.
See "Reconnect Data Cables and Power Cords" on page
See "Power On the Server" on page
Verify that the Power/OK status indicator is steady on.
145.
149.
150.
148.
