System Chassis Components

The following table lists the system chassis components.
Component Name
(Oracle ILOM CLI
Targets) IPMI Type
/SYS FRU
/SYS/UUID FRU
/SYS/ACPI State
sensor
/SYS/PWRBS Discrete
sensor
/SYS/VPS Threshold
sensor
/SYS/VPS_CPUS Threshold
sensor
/SYS/VPS_MEMO Threshold
RY sensor
/SYS/VPS_FANS Threshold
sensor
/SYS/INTSW Discrete
sensor
Description
General host FRU
Unique system ID
Precondition for sensors
that need to know if the
host is on
Power budget status
Virtual power sensor
Virtual power sensor
(CPUs)
Virtual power sensor
(Memory)
Virtual power sensor
(Fans)
Chassis intrusion switch
Monitoring Components and Identifying SNMP Messages
Values
(if applicable)
Derived from host MAC
address. Use for PXE boot
and licensing.
(hidden)
01h-ACPI_ON_WORKING
20h-ACPI_SOFT_OFF
01h-DEASSERTED
02h-ASSERTED
Watts
Watts
Watts
Watts
01h-DEASSERTED
02h-ASSERTED
