Storage Drive Status Indicators

There are three status indicators (LEDs) on each drive.
Server Front Storage Drive Indicators
TABLE:
Status
Indicator
Name Icon
OK to
Remove
Service
Required
OK/Activity
Related Information
"Front Panel Controls and Indicators on a System With Eight 2.5-inch Drives" on
■
page 3
"Front Panel Controls and Indicators on a System With Four 2.5-inch Drives and
■
DVD Drive" on page 4
"Server Back Panel View" on page 5
■
"Servicing Storage Drives (CRU)" on page 45
■
10 Sun Server X4-2 Service Manual • May 2014
Color State Meaning
Blue • STEADY ON – The storage drive can be removed safely during a
hot-plug operation.
• OFF – The storage drive has not been prepared for removal.
Amber • OFF – The storage drive is operating normally.
• STEADY ON – The system has detected a fault with the storage drive.
Green • OFF – Power is off or the installed drive is not recognized by the system.
• STEADY ON – The drive is engaged and is receiving power.
• STEADY BLINK – There is disk activity. The LED blinks on and off to
show activity.
