DIMM Population Order for Single-Processor Systems

In single-processor systems, DIMMs should only be installed into DIMM sockets
associated with processor 0 (P0) starting with P0 D0, first filling the blue sockets and
then the white. This DIMM population order is illustrated in
Population Order on page
The following table describes the order in which the DIMM sockets should be
populated in single-processor systems. The figure callouts in column two of the table
refer to the callouts in
TABLE:
Population
Order
Fill the blue sockets first
First
Second
Third
Fourth
Then fill the white sockets
Fifth
Sixth
Seventh
Eighth

DIMM Population Order for Dual-Processor Systems

In dual-processor systems, DIMMs should be installed into DIMM sockets starting
with P0 D0 and then alternating between sockets associated with processor 0 (P0)
and matching sockets for processor 1 (P1), first filling the blue sockets and then the
white. This DIMM population order is illustrated in
Order on page
The following table describes the order in which the DIMM sockets should be
populated in dual-processor systems. The figure callouts in columns two and four of
the table refer to callouts in
66 Sun Server X4-2 Service Manual • May 2014
65.
FIGURE: DIMM Population Order on page
DIMM Population Order for Single-Processor Systems
Figure Callouts DIMMs Sockets for Processor 0 (P0)
1 D0
3 D2
5 D5
7 D7
9 D1
11 D3
13 D4
15 D6
65.
FIGURE: DIMM Population Order on page
FIGURE: DIMM
65.
FIGURE: DIMM Population
65.
