Remove A Processor - Sun Oracle Sun Server X4-2 Service Manual

TABLE:
Processor Cores
4-core
6-core
8-core
10-core
12-core
Note – The correct processor removal/replacement tool is included in the box with
the replacement processor. Additionally, both removal/replacement tools ship with
replacement motherboards.

▼ Remove a Processor

Caution – Processors should be removed only by an Oracle qualified service
technician.
Caution – Processor removal and replacement must be done using the correct
removal/replacement tool; otherwise, damage might result to the processor or the
processor socket. For information on how to select the correct removal/replacement
tool, see
Caution – Be careful not to touch the processor socket pins. The processor socket
pins are very fragile. A light touch can bend the processor socket pins and damage
the board beyond repair. Always use the processor removal/replacement tool to
remove and replace the processor.
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
106 Sun Server X4-2 Service Manual • May 2014
Processor Model Numbers by Number of Cores
Processor Model Number
E5-2609 V2
E5-2630 V2
E5-2650 V2
E5-2690 V2
E5-2697 V2
"Selecting the Correct Processor Removal/Replacement Tool" on page
supplies.
See "Powering Down the Server" on page
Processor
Removal/Replacement Tool
Color Code
Green
Pink
33.
102.
