Remove A Pcie Card From Pcie Slot 1 - Sun Oracle Sun Server X4-2 Service Manual

▼ Remove a PCIe Card From PCIe Slot 1 or 2
Note – PCIe slot 1 is nonfunctional in single-processor systems.
1. Remove the PCIe riser from the server.
For instructions, see
2. Remove the PCIe card from the PCIe riser.
a. Hold the riser in one hand and use your other hand to carefully pull the PCIe
b. Disconnect the rear bracket that is attached to the PCIe card from the rear of
3. Place the PCIe card on an antistatic mat.
Caution – Whenever you remove a PCIe card, you should replace it with another
PCIe card or a PCIe filler panel. Installing PCIe filler panels in vacant PCIe slots
helps reduce the level of electromagnetic interference (EMI) emitted by the server.
For instructions for installing a PCIe filler panel, see
Filler Panels" on page
86 Sun Server X4-2 Service Manual • May 2014
"Remove a PCIe Riser From PCIe Slot 1 or 2" on page
card connector out of the riser.
the PCIe riser.
143.
"Removing and Installing Server
76.
