BIOS Main Menu Selections

This section includes a searchable text-based representation and a screenshot of the
BIOS Main Menu. The options that are available from the Main Menu are described
in the table that follows. Options in the table that are marked as "(R/O)" are
read-only information and cannot be changed.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
/----------------------------------------------------+-----------------------\
| Project Version
| System Date
| System Time
|
| Active Logical Cores
| QPI Link Speed
| Total Memory
| Current Memory Speed
| USB Devices:
| 1 Drive, 1 Keyboard, 1 Mouse, 3 Hubs
|
|
|BMC Firmware Status
|BMC Firmware Revision
|
|> Product Information
|> CPU Information
|> DIMM Information
|
|> Security Setting
---------------------------------------------------+-------------------------/
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
198 Sun Server X4-2 Service Manual • May 2014
IO Boot UEFI Driver Control
25.01.05.00
[Sat 07/16/2013]
[19:58:46]
40
8.0 GT/s
16 GB (DDR3)
1333 MHz
Healthy
3.1.2.0 r78939
Save & Exit
|Set the Date. Use Tab
|to switch between Data
|elements.
|
|
|
|
|
| ----------------------|
|><: Select Screen
|^v: Select Item
|
|Enter: Select
|+/-: Change Opt.
|F1: General Help
|(Ctrl+Q from serial
|keyboard)
|Q: Scroll Help Pane Up
|A: Scroll Help Pane Down|
|ESC: Exit
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
