DTC "C12" (P0335): CKP Sensor Circuit Malfunction
Detected Condition and Possible Cause
Detected Condition
Although the intake pressure is fluctuated, the signal
does not reach for 3 sec. or more.
NOTE
If SDS is used, P0355 is indicated.
Wiring Diagram
CKP sensor
Generator
• Metal particles or foreign material being attached on the
• CKP sensor circuit open or short.
• CKP sensor malfunction.
• ECM malfunction.
G
Bl
To regulator/rectifier
Engine General Information and Diagnosis:
Possible Cause
CKP sensor and rotor tip.
G/W
BI
1A-22
B705H11104016
ECM
(3) CKP
(9) CKP
