California Proposition 65 Warning
WARNING
Operating, servicing and maintaining a passenger
vehicle or off-road vehicle can expose you to
chemicals
including
engine
exhaust,
carbon
monoxide, phthalates, and lead, which are known to
the State of California to cause cancer and birth
defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in
a well-ventilated area and wear gloves or wash your
hands frequently when servicing your vehicle. For
more information go to www.P65Warnings.ca.gov/
passenger-vehicle.
This manual should be considered a permanent part of the
motorcycle and should remain with the motorcycle when resold
or otherwise transferred to a new owner or operator. The
manual contains important safety information and instructions
which should be read carefully before operating the motorcycle.
