Suzuki AN400 Service Manual page 57

Tightening Torque Chart
For other bolts and nuts not listed in the preceding page, refer to this chart:
Bolt Diameter
"a" (mm) N⋅m
4 1.5
5
6 5.5
8 13
10 29
12 45
14 65
16 105
18 160
" a "
Conventional or "4" marked bolt
kgf-m
0.15
3 0.3
0.55
1.3
2.9
4.5
6.5
10.5
16.0
1
"a"
1. Conventional bolt
lb-ft N⋅m
1.0 2.3
2.0 5
4.0 10
9.5 23
21.0 50
32.5 85
47.0 135
76.0 210
115.5 240
2
2. "4" marked bolt 3. "7" marked bolt
Service Data:
"7" marked bolt
kgf-m lb-ft
0.23 1.5
0.5 3.5
1.0 7.0
2.3 16.5
5.0 36.0
8.5 61.5
13.5 97.5
21.0 152.0
24.0 173.5
3
"a "
