Transmission
Unit: mm (in) Except ratio
Item
Primary reduction ratio
Reduction ratio
Secondary reduction ratio
Final reduction ratio
Drive V-belt width
Movable driven face spring free
length
Movable drive face roller O.D.
Drive/driven face ware
Injector + Fuel Pump + Fuel Pressure Regulator
Item
Injector resistance
Fuel pump discharge amount
Fuel pressure regulator operating
set pressure
FI Sensors
Item
CKP sensor resistance
CKP sensor peak voltage
IAP sensor input voltage
IAP sensor output voltage
TP sensor input voltage
TP sensor output voltage
ECT sensor input voltage
ECT sensor resistance
IAT sensor input voltage
IAT sensor resistance
TO sensor resistance
TO sensor output voltage
Injector voltage
Ignition coil primary peak voltage
HO2 sensor resistance
HO2 sensor output voltage
STP sensor input voltage
STP sensor output voltage
STP actuator resistance
Specification
1.000
2.200 – 0.839
2.214
2.666
25.1 (0.99)
150.0 (5.90)
26.00 – 26.16 (1.024 – 1.030)
Specification
Approx. 10.3 Ω at 20 °C (68 °F)
35 ml and more
For 10 sec., at 300 kPa (3.0 kgf/cm
Approx. 300 kPa (3.0 kgf/cm
Specification
190 – 290 Ω
4.5 V and more (When cranking)
4.5 – 5.5 V
Approx. 1.5 – 3.5 V at idle speed
4.5 – 5.5 V
Closed
Opened
4.5 – 5.5 V
Approx. 2.58 kΩ at 20 °C (68 °F)
4.5 – 5.5 V
Approx. 2.58 kΩ at 20 °C (68 °F)
16.5 – 22.3 kΩ
Normal
Leaning
Battery voltage
150 V and more (When cranking)
11.5 – 14.5 Ω at 23 °C (73.4 °F)
Idle speed
3 000 r/min
4.5 – 5.5 V
Closed
Opened
Approx. 6.5 Ω
—
, 43 psi)
2
2 , 43 psi)
Approx. 0.6 V
Approx. 3.8 V
0.4 – 1.4 V
3.7 – 4.4 V
0.3 V and less
0.7 V and more
Approx. 0.5 V
Approx. 3.9 V
Service Data: 0C-3
Note
—
—
—
24.1 (0.95)
142.5 (5.61)
—
0.4 (0.02)
Note
—
—
—
Note
(+) probe: G/W,
(–) probe: Bl
(+) probe: W,
(–) probe: Ground
