12. Brake hose union bolt (Front & Rear)
: 23 N⋅m (2.3 kgf-m, 16.5 lb-ft)
14
(n)
14. Rear shock absorber mounting bolt/nut
(Upper & Lower)
: 50 N⋅m (5.0 kgf-m, 36.0 lb-ft)
16
15
15. Cushion lever nut
16. Cushion rod nut
I705H1020063-03
I705H1020064-01
(p)
16
(p)
(o)
I705H1020065-01
: 50 N⋅m (5.0 kgf-m, 36.0 lb-ft)
: 50 N⋅m (5.0 kgf-m, 36.0 lb-ft)
Maintenance and Lubrication:
18
(r)
17. Engine mounting nut
18. Crankcase bracket nut
19. Rubber damper bolt
20
(t)
20. Exhaust pipe bolt
21. Muffler connecting bolt
22
(v)
22. Muffler mounting bolt
0B-18
19
(s)
17
(q)
I705H1020066-04
: 93 N⋅m (9.3 kgf-m, 67.0 lb-ft)
: 85 N⋅m (8.5 kgf-m, 61.5 lb-ft)
: 85 N⋅m (8.5 kgf-m, 61.5 lb-ft)
21
(u)
I705H1020067-01
: 23 N⋅m (2.3 kgf-m, 16.5 lb-ft)
: 23 N⋅m (2.3 kgf-m, 16.5 lb-ft)
22
(v)
I705H1020068-01
: 23 N⋅m (2.3 kgf-m, 16.5 lb-ft)
