Sea-doo RX Shop Manual page 330

Section 13 TECHNICAL DATA
Subsection 01 (RX MODEL)
ELECTRICAL
Magneto generator output
Ignition system type
Spark plug
Ignition timing (BTDC)
Battery charging coil
Trigger coil
Ignition coil
Engine rev limiter setting
Battery
Fuses
ADDITIONAL INFORMATION:
CARBURETION
Carburetor
Main jet
Pilot jet
Spring
Adjustment
Fuel
Fuel return line orifice
ADDITIONAL INFORMATION:
COOLING
Type
Thermostat
Monitoring beeper setting
ADDITIONAL INFORMATION:
13-01-2
Make and type
Gap
mm (in)
Degrees
Primary
Secondary
MPEM
Electrical system
VTS system
Bilge pump
Type
Quantity
Low-speed screw
High-speed screw
Idle speed (in water)
Idle speed (out of water)
Type
Minimum octane no.
www.SeaDooManuals.net
RX (5513/5514)
180 W @ 6000 RPM
Digital DC-CDI
NGK BR8ES
0.5 - 0.6 mm (.020 - .024 in)
2.99 (.118)
20° ± 1 @ 3500 RPM
0.1 - 1 Ω
190 - 300 Ω
0.33 - 0.62 Ω
8.4 - 15.6 k Ω
7200 (± 50) RPM
12 V, 19 A•h (Yuasa/Exide)
5 A
2 x 15 A
7.5 A
3 A
RX (5513/5514)
Mikuni BN-46i (diaphragm), fuel accelerator pump
2
MAG and PTO: 162.5
75
95 g
1-1/2 turn ± 1/4
0
1400 ± 100 RPM
3000 RPM
Regular unleaded gasoline
87
MAG and PTO: 0.8 mm (.031 in)
RX (5513/5514)
Open circuit — Direct flow from jet propulsion unit
None
86 - 94°C (187 - 201°F)
