Section 09 ELECTRICAL SYSTEM
Subsection 05 (INSTRUMENTS AND ACCESSORIES)
NOTE: If maintenance message (MAINT) con-
tinues to blink, it indicates a fault with the fuel in-
jection system on Di models. Refer to DIAGNOS-
TIC PROCEDURES section.
Verification
The PURPLE wire is the 12 Vdc power source of
the Information Center.
The BLACK wire is the ground.
The RED/PURPLE wire is the 12 Vdc from the bat-
tery. It is protected by a fuse on the MPEM; the
fuse "MPEM" on the carburetor-equipped mod-
els and the fuse "ACC" fuse on DI models.
The accuracy of some features of the Information
Center can be checked with a potentiometer.
Fuel Level
Disconnect the 4-circuit connector housing of the
Information Center.
Using an appropriate terminal remover, remove
the PINK wire from the tab housing.
Reconnect the connector housing.
Disconnect the 2-circuit connector housing which
contains a PURPLE and BLACK wires.
Remove the BLACK wire from the receptacle
housing.
Reconnect the connector housing.
Connect potentiometer test probes to the PINK
and BLACK wires.
Adjust potentiometer to the resistance values as
per following chart to test the accuracy of the gauge.
NOTE: The gauge must be activated to obtain a
reading.
RESISTANCE
FUEL LEVEL
(Ω)
LCD GRAPHIC
0 + 2.2
FULL
17.8 ± 2.2
7/8
27.8 ± 2.2
3/4
37.8 ± 2.2
5/8
47.8 ± 2.2
1/2
57.8 ± 2.2
3/8
67.8 ± 2.2
1/4
77.8 ± 2.2
1/8
89.0 ± 2.2
EMPTY
09-05-6
RX and RX DI
VTS
Disconnect the 2-circuit connector housing of the
Information Center.
Connect potentiometer test probes to the BROWN/
WHITE and BROWN/BLACK wires.
Adjust potentiometer to the resistance values as
per following chart to test the accuracy of the gauge.
NOTE: The gauge must be activated to obtain a
reading.
All Models
Water Temperature (L temp)
Disconnect the 2-circuit connector housing of
LOW FUEL
the Information Center which contains a BLACK/
LEVEL RED
ORANGE and TAN/ORANGE wires.
LIGHT
Connect potentiometer test probes to the BLACK/
OFF
ORANGE and TAN/ORANGE wires.
Adjust potentiometer to the resistance values as
OFF
per following chart to test the accuracy of the gauge.
OFF
NOTE: The gauge must be activated to obtain a
OFF
reading.
OFF
OFF
OFF
ON
ON
www.SeaDooManuals.net
RESISTANCE
(Ω)
167.3 ± 2.2
153.0 ± 2.2
138.7 ± 2.2
124.4 ± 2.2
110.1 ± 2.2
95.8 ± 2.2
81.5 ± 2.2
67.2 ± 2.2
52.9 ± 2.2
38.6 ± 2.2
24.3 ± 2.2
RESISTANCE
(Ω)
TEMPERATURE (°C)
25407.3
19911.1
15718.0
VTS LEVEL LCD
GRAPHIC
11/11 (UP)
10/11
9/11
8/11
7/11
6/11
5/11
4/11
3/11
2/11
1/11 (DOWN)
DISPLAY
5 ± 2
10 ± 2
15 ± 2
SMR2000-063_09_05A.FM
