Sea-doo RX Shop Manual page 266

To remove impeller, apply a rotating movement
and pull at same time. Slide impeller out of hous-
ing. Remove tool from impeller.
Wear Ring
Place jet pump housing in a vise with soft jaws. It
is best to clamp housing using a lower ear.
Remove wear ring screws.
Cut wear ring at two places.
NOTE: Wear ring can be cut using a jigsaw, a small
grinder or a low clearance hacksaw such as Snap-
on HS3 or equivalent.
CAUTION: When cutting ring, be careful not to
damage jet pump housing.
TYPICAL
TYPICAL
1. Snap-on HS3
After cutting ring, insert a screwdriver blade be-
tween jet pump housing and ring outside diameter.
Push ring so that it can collapse internally.
Pull ring out.
SMR2000_065_10_02A.FM
Section 10 PROPULSION SYSTEM
Impeller Shaft
Remove shaft holder tool.
Remove impeller shaft no. 21 with thrust washer
and thrust bearing.
Seal and Needle Bearing
Remove seal no. 19 and bearings no. 20 at the
same time using bearing/seal remover tool (P/N
295 000 144).
Insert bearing remover then press tool using a ar-
bor press until seal and bearings are out. However,
care should be taken not to damage bearing journals.
F00J0MA
1. Bearing/seal remover tool
NOTE: It is always recommended to renew both
bearings, even if only one bearing needs to be re-
placed.
www.SeaDooManuals.net
Subsection 02 (JET PUMP)
1
10-02-9
