Sea-doo RX Shop Manual page 251

RESISTANCE
(Ω)
12495.0
10000.0
8054.9
6528.3
RESISTANCE
(Ω)
22799.0
17262.0
13470.0
10496.3
8264.4
6528.3
Exterior Temperature (if so equipped)
Disconnect the 2-circuit connector housing of the
Information Center which contains a TAN/WHITE
and BLACK/WHITE wires.
Connect potentiometer test probes to the TAN/
WHITE and BLACK/WHITE wires.
Adjust potentiometer to the resistance values as
per following chart to test the accuracy of the
gauge.
NOTE: The gauge must be activated to obtain a
reading.
RESISTANCE
(Ω)
25590.1
20005.8
15761.7
12510.2
10000.0
8047.8
6518.7
SMR2000-063_09_05A.FM
Subsection 05 (INSTRUMENTS AND ACCESSORIES)
DISPLAY
TEMPERATURE (°C)
20 ± 2
25 ± 2
30 ± 2
35 ± 2
DISPLAY
TEMPERATURE (°F)
45 ± 4
55 ± 4
65 ± 4
75 ± 4
85 ± 4
95 ± 4
DISPLAY
TEMPERATURE (°C)
5 ± 2
10 ± 2
15 ± 2
20 ± 2
25 ± 2
30 ± 2
35 ± 2
www.SeaDooManuals.net
Section 09 ELECTRICAL SYSTEM
RESISTANCE
(Ω)
22919.8
17491.7
13487.5
10501.5
8252.0
6518.7
Fuel Baffle Pick Up Sender
Carburetor-Equipped Models
The baffle pick-up has an integrated fuel sender.
To verify fuel sender, a resistance test should be
performed with a multimeter allowing the float to
move up through a sequence.
F01F20A
1. Pick up tube
2. Fuel sender
3. Baffle pick-up
The resistance measured between PINK/BLACK
and PINK wires must be in accordance with fuel
level (measured from under the flange) as speci-
fied in the following charts.
DISPLAY
TEMPERATURE (°F)
45 ± 4
55 ± 4
65 ± 4
75 ± 4
85 ± 4
95 ± 4
1
2
3
09-05-7
