The Properties Display; All Device Groups Properties - Extreme Networks EPICenter Reference Manual

Search:
By Device Name
By IP Address
In <Device Group>
Of <Device Type>
3 Click Find to search for devices that meet the criteria you have specified.
Click New Search to clear all search criteria.
All devices found are listed in the center panel. Information includes the device group in which the
device can be found, its name, IP address, and the type of device. There is one entry for each device
or device group combination.
4 To view details about a device in the results table, you can either:
Double-click a device entry in the results table, or
■
Select a device entry and click Go to.
■
If you double-click a device result, the Find Devices window remains open; if you click Go to, the
window closes.

The Properties Display

You can view the properties of a device group or a device in the EPICenter database. This section
describes the information displayed in the various properties windows.
Most of the information in the various Properties displays is shown in columnar form. The columns can
be resized by "grabbing" the separator between two column headings, and the display can be sorted by
clicking on a column heading. The column heading shown in green indicates the column used to sort
the display. See "Resizing Columns" on page 36
instructions.

All Device Groups Properties

The Device Groups Properties window shows summary information for all device groups (see
Figure 40). To display this window, select the top-level Device Groups item in the Component Tree, then
select Properties from the Display menu, or from the right-click pop-up menu.
EPICenter Reference Guide
Enter a complete or partial device name or IP address into this field.
* acts as a wildcard for an entire octet (0-255), or for the rest of the string
?
is a wildcard for a single digit (0-9) or character
Select the appropriate radio button to indicate whether this is a name or IP address.
To find all devices in a device group or of a selected device type, leave this field
blank and select the appropriate Device Group and Device Type
Select to indicate that the value in the Search: field is a complete or partial device
name. You can use the wild card characters * or ? in the search criteria.
Select to indicate that the value in the Search: field is a complete or partial IP
address. You can use the wild card characters * or ? in the search criteria.
Limits the search to the selected Device Group. Select the device group from the
drop-down menu. If you do not specify a name or IP address in the Search field, all
devices in the device group you select are found.
Limits the search to the selected Device Type. Select the device type from the drop-
down menu in the Device Type field. If you do not specify a name or IP address in
the Search field, all devices of the type you select are found.
and "Sorting Columns" on page 36
The Properties Display
for more detailed
