Voice VLAN Summary (Voice Over IP Reports)

To view a report of the voice VLANs known to the EPICenter software, click the Voice VLAN
Summary link in the left-hand panel.
Figure 202: Voice Over IP Reports (Voice Vlan Summary)
The information reported includes the following:
VoIP Vlan Name Name of the VLAN
Device List IP addresses of devices with ports that are members of this VLAN, and the QoS Profile
configured for this VLAN on each device
Click on a VLAN name to display the Voice over IP Details report for the devices in the VLAN.
The Voice over IP Details report displays the following information:
Device Name Name of the device
IP Address IP address of the device
VLAN IP The IP address and subnet mask assigned to the VLAN (if any) on the switch
Egress Port List The ports specified as Egress ports for the VoIP VLAN
Number of Phone Ports The number of ports that are available for use as IP phone ports
Click the VLAN name to display a detailed report for an individual VLAN.
EPICenter Reference Guide
Figure 202 shows example output.
