Network Topology Views

The View Menu

View Properties...

You can change the properties you set when you created a new view (or change the properties of the
Default view) using the View Properties... function. To display the View Properties window, do one of
the following:
Select View Properties... from the View menu.
●
Right-click on the map background to display the pop-up menu, then select View Properties...
●
The View Properties window appears, as shown in
Figure 142: Setting View properties for the current view
The fields in the View Properties dialog box are as follows:
View Name
Auto populate view
View Alarm Status Threshold
304
Figure
The current view name is displayed here.
Check to add the devices currently in the EPICenter inventory database to the new
View. Submaps and hyper nodes are created as needed.
In addition, as new devices are added to EPICenter, they are also added to the
view. If you do a Discovery after you have created a view with the auto populate
option enabled, all new discovered devices will be added to the view automatically.
See "Node Placement Criteria in an Auto Populate View" on page 293
information.
The lowest alarm severity level for which an alarm icon should be displayed. If the
level is set to one of the higher levels, then lower-severity alarms will not cause an
icon to appear. Changing this affects status for alarms that occur after this setting
is changed.
142.
for detailed
