Figure 268: AccessList display showing rules for an i-series device
The View field at the top of the display lets you select how you want to view the device rules. You can
view the Access List rules in three ways:
Compare policy and configured
rules
View policy rules
View configured rules

Policy Rule Comparison

The policy rule comparison display shows both the ideal rules, as generated by the EPICenter Policy
Manager (shown in the left half of the table) and the configured rules as they exist on the device, shown
in the right half of the table.
The rows in the comparison display are displayed in colors that indicate the status of the rule:
Green The rule is a valid rule (is not in conflict with a rule already on the device), but that it
has not been configured on the device. Only the Ideal side of the table is filled in for
these rules.
White The rule is valid, and has been configured on the device. Both the Ideal and Configured
sides of the table are filled in.
EPICenter Reference Guide
Select to compare the EPICenter-generated rules with the rules configured on the
device (as shown in Figure 268).
Select to display the EPICenter rules only.
Select to display the configured rules only.
