The fields in this window are as follows:
Top N Display Count Specifies the number of ports to include in a Top N display. The default is 15,
maximum is 100.
Pie Slice Display Count Specifies the number of slices to display in a pie chart. The default is 10, maximum is
50.
Historical Data Display Specifies the number of historical data points to display in a graph for an individual
Count port. The default is 50, the maximum value you can set is 100. However, the actual
maximum number of data points you can get is determined by the SNMP agent running
in the device from which you are getting data.
Historical Data Sampling The sampling interval to use when displaying historical data. Select a choice from the
Interval pull-down list. The choices in the list are determined by the configuration of the device
from which you are getting data.

Taking Graph Snapshots

The Real-Time Statistics Snapshot feature lets you take a static image of a graph or table view of the
current real-time statistics data. The snapshot generates a persistent HTML page that is displayed in a
separate window (see Figure
EPICenter Reference Guide
127).
