Table 33: The Tools Menu
Device >
Macros >

Pop-Up Menus

The Topology Viewer provides three pop-up menus:
When you select a device in the current map view, you can right-click to display a pop-up menu
●
that contains commands relevant to the selected device.
When you select a submap in the current map view, you can right-click to display a pop-up menu
●
that contains a command for enabling or disabling alarm propagation at the submap level.
You can right-click on the map background to display a pop-up menu with commands that let you
●
modify the currently selected map.
See "Right-Click Pop-Up Menus" on page 38
up menus.
Device Node Pop-Up Menu
The pop-up menu that appears when you right-click on a device node contains the following
commands:
Table 34: Device Node Pop-Up Menu Commands
Connect Edge Port to VLAN
Disable Alarm Propagation/
Enable Alarm Propagation
Device >
Technical Support >
Macros >
Properties
EPICenter Reference Guide
Enables you to view other types of information about a device (from other
EPICenter applets) without having to leave the Topology View. Provides a
submenu of commands that run in a separate window with the device
preselected: Alarms, Statistics, Sync, Telnet, Viewer, VLANs, Device
Manager. See "The Device Sub-Menu" on page 39
each command.
Displays a list of Telnet macros available for the selected device. See
Macros Sub-Menu" on page 41
for basic information about using the device-related pop-
Same as the Connect Edge Port to VLAN command from the Tools menu.
Opens the Connect Edge Port to VLAN Wizard, which guides you through
adding edge ports from a selected device to a VLAN. See
Port to VLAN" on page 320.
Enables or disables Alarm Propagation for the selected device. If disabled,
this device will not be included when determining the alarm status at the
map level.
When a device has Alarm Propagation disabled, the alarm status for the
device is still be displayed as appropriate, but the alarm icon appears with
an "X" through it.
Same as the Device command from the Tools menu. Provides a submenu of
commands: Alarms, Statistics, Sync, Telnet, Viewer, VLANs, Device
Manager. See "The Device Sub-Menu" on page 39
command.
Same as the Technical Support command from the Tools menu.
See "The Technical Support Sub-Menu" on page 40
Same as the Macros command from the Tools menu. See
Menu" on page 41 for more information.
Same as the Properties command from the Display menu. See
Properties Display" on page 85
Topology Manager Functions
for a description of
for more information.
"Connect Edge
for a description of each
for details.
"The Macros Sub-
for details about what this command shows.
"The
"The
