Using the IP/MAC Address Finder
Remove All
Target Domains
To create a search task to do a Database search:
1 Provide a name in the Task Name field.
2 Define the search targets.
You can paste a MAC address or IP address into the address field; place the cursor into the first cell
of the address and paste an address you have copied, using your system's keyboard paste command
(Ctrl-V in Windows). For example, you might copy an address from a report or a syslog entry to
paste into the IP/MAC Address Finder.
3 Select Database as the search type.
4 Click the Submit button at the bottom of the window to initiate the search.
NOTE
A Database search is only available if you have MAC Polling Enabled. If you specify a database search, you
cannot specify a search domain; the entire EPICenter database will be searched.
To create a search task to do a Network search:
1 Provide a name in the Task Name field.
2 Define the search targets.
3 Select Network as the search type.
4 Define the search domain. The Target Domains list specifies the scope of the devices to be included
in the search. Devices not included in this domain are not searched.
Select the devices, ports, Device Groups, or Port Groups that you want to search and click the Add
button to move them into the Target Domains list.
You can create a target domain that includes a combination of these specifications.
NOTE
The IP/MAC Address Finder applet does not support hierarchical port groups. If you have created port groups in
the Grouping Manager that include subgroups as members, those subgroups will not appear in the Target
Domains list. Instead, any ports that are members of subgroups will be displayed directly under the top-level port
group, as if they are members of the top-level group.
5 When you have completed your search specification, click the Submit button at the bottom of the
window to initiate the search.
256
Removes all components from the Target Domains list.
Lists the devices, device groups (domains), ports, or port groups to be included in the
search. Devices not included in the Target Domain will not be searched.
Select the Device, Port, Device Group, or Port Group that you want to search and click
the Add button to move it into the Target Domains list.
For each item you have added to the Target list, the following is displayed:
Type: The type of target—Devices, Device Groups, Ports, Port Groups
Value: The name, IP address, or port number of the selected target
Device Status: If the target is a device or port, shows the status of the device: Online or
Offline/Down
To remove a member from the Target Domains list, select the item in the list and click
Remove. To clear the Target Domains list, click Remove All.
