Unused Ports Report - Extreme Networks EPICenter Reference Manual

EPICenter Reports
Because the EPICenter server may be aware of many hundreds of ports, the interface information is
displayed in groups of 25 ports per page. You can navigate among the pages using any of the following
methods:
Clicking the Previous and Next links
●
Selecting a page number from the at the top of the report
●
Clicking the First or Last links to display the first or last page in the report
●
The list of ports is sorted initially by IP address. Click the heading of a column to sort the report based
on the contents of that column; for example, to sort by operational status, click on the OperStatus
heading.
You can filter the ports that are displayed by constructing a conditional filter using the fields at the top
of the page. This lets you construct a two-clause filter statement;
Figure 197: Device Ports filter specification
For more information on the filtering choices, see
pages.

Unused Ports Report

To see inactive ports for a particular device, click the Unused Ports link in the left-hand panel.
Figure 198 shows example output.
402
Figure 197
"Using Report Filtering" on page 379
shows an example.
and following
EPICenter Reference Guide
