EAPS Protocol Monitoring and Verification
Figure 245: The EAPS Monitor showing the Links Tab
You can sort the rows in the Devices table based on the one or more columns. See
Display" on page 466
The Links table shows the following information:
Table 55: Columns in the Links Table
Column
(Link Operational State)
(EAPS Shared Port
Present)
DP (Link Discovery Protocol)
Type
Device Name
IP Address
Port
Device Name
476
for details.
Blank if the link is up, shows a red Stop symbol (red circle with diagonal line) if
the link is down.
Whether a shared port is present on this link. SP indicates a shared port is
present. Click the link (SP) to display the Shared Port information window (See
The discovery protocol enabled on the link (EDP, LLDP, or EDP and LLDP)
The link type (speed)
The name of the device at one endpoint of the link. Click the device name to
display the Device Properties window (see
The IP address of the first endpoint device. Clicking the IP address also displays
the Device Properties window.
The port on which the link exists on the first endpoint device. Click the port
number to display the Port Properties window (see
The name of the device at the other endpoint of the link. Click the device name
to display the Device Properties window (see
"Sorting a Table
"Device Properties" on page
"Port Properties" on page
"Device Properties" on page
