Extreme Networks EPICenter Reference Manual page 507

Figure 265: Message window showing policy configuration progress
Devices are listed followed by a small purple rotating clock icon
in progress.
When a configuration has been successful, the clock turns into a green checkbox
●
If the configuration fails, the clock turns into a red X
●
The indicators just below the tree area of the window show the number of devices currently in each
state.
To see the messages related to the configuration function (either successful or unsuccessful), select a
device in the list. The messages related to the device are displayed as lines under the device node.
Plus sign Click the plus sign at the left of the device name to display server messages related to
configuring the device.
Minus sign Click the minus sign at the left of the device to hide the server messages.
Up and down arrows The up and down arrow buttons let you move up and down the device tree, displaying
the server messages associated with each device.
Errors Only If you check the Errors Only box, the up and down arrow buttons will expand only
devices that had errors.
Collapse All The Collapse All button collapses all the device nodes, hiding all the server messages.
EPICenter Reference Guide
Configuring QoS Policies
while the configuration function is
and the device name is displayed in red.
.
507
